MAV 1204

Features

  • rigid shaft-to-shaft coupling
  • medium capacity
  • three-part design
  • compact design
  • self-releasing tapers, greased with MoS2 (μ = 0.05). Oiled tapers (self-locking) up to size 14×44
  • screws greased with MoS2 (μ = 0.10)
  • connection of shafts with different diameters is possible, through stepped bore inner ring or adapter sleeve
  • shafts tolerance: h7 – h9
  • shafts surface finish Ra < 3.2 μm
  • shafts – coupling contact surfaces: oiled (μ = 0.12)

Composition

  • slotted inner ring
  • front outer ring
  • rear outer ring
  • set of hexagonal head cap screws, grade 10.9 (size < M6 of grade 8.8)
